EM-Tec CT ESD safe replaceable plastic tip tweezers
soft tip tweezers with a firm stainless steel handles


An example
EM-Tec 2A.CT ESD safe carbon fiber replaceable tip tweezers, flat wide tips

Introduction

The EM-Tec replaceable plastic tip tweezers combine the advantages of the soft tip ESD safe tweezers with the firm handles of stainless steel tweezers. The material used for the replaceable plastic tips is the same as for the EM-Tec CT plastic tweezers:  ESD safe, tough material with excellent chemical resistance. The handles of the tweezers are the same as for the EM-Tec high precision anti-magnetic tweezers.
ESD safe soft plastic tipped tweezers are ideal for handling scratch sensitive materials such as aluminium, brass, copper and plastics. The softer plastic tips are also better for handling silicon chips or glass to avoid damage and debris. When the tips are worn out or damaged they can be easily replaced with another pair of precision tips, which are separately available.

The ESD safe EM-Tec CT ESD safe replaceable tips are made from PVDF polyvinylidene fluoride and carbon fibre reinforced (30%). This material shares many properties with PTFE.  These tips combine excellent mechanical strength and toughness with superb chemical resistance. They are heat stabilised, have a high heat capacity and can be used continuously at temperatures up to 150°C. Fully clean room compatible due to high abrasion resistance with low particle extraction value.  Excellent chemical resistance to solvents, mineral oils, halogens, nitric acid, hydrochloric acid and hydrofluoric acid. Resistant to UV and nuclear radiation. Fully ESD safe material.  The anti-magnetic stainless steel handles provide excellent grip and enables reverse style tipped tweezers as well. Available in 11 different styles, including 3 styles of reversed tweezers to cover a wide variety of applications. For etching applications where the handles of the tweezers can be affected, we advise using the EM-Tec ESD safe plastic tweezers.

For comprehensive chemical data on the EM-Tec CT replaceable tips, consult the Chemical Compatibility Chart.


Specifications of the EM-Tec CT ESD safe replaceable plastic tip tweezers

Product #

Tip Style

Description

Length

Points size – W x H

50-007000

EM-Tec  00.CT

Blunt

130mm

1.0 x 1.0mm

50-007020

EM-Tec  2A.CT

Flat, wide

130mm

1.8 x 0.5mm

50-007025

EM-Tec  2AB.CT

Flat, wide, curved

130mm

1.8 x 0.5mm

50-007026

EM-Tec  242.CT

Flat, narrow

130mm

1.4 x 0.6mm

50-007027

EM-Tec  249.CT

Blunt, strong

130mm

2.2 x 1.1mm

50-007029

EM-Tec  259.CT

Sharp

130mm

0.6 x 0.5mm

50-007050

EM-Tec  5.CT

Sharp, fine

130mm

0.5 x 0.3mm

50-007060

EM-Tec  246.CT

Pointed, bent

130mm

0.6 x 0.4mm

50-007070

EM-Tec  7.CT

Fine, curved

130mm

0.6 x 0.3mm

50-007082

EM-Tec  2AX.CT

Flat, wide, reversed

130mm

1.8 x 0.5mm

50-007085

EM-Tec  5X.CT

Sharp, fine, reversed

130mm

0.5 x 0.3mm



Ordering information for the EM-Tec CT ESD safe replaceable plastic tip tweezers

*Prices without VAT, but within the EU, we have to check for valid VAT-ID.

50-007000-EM-Tec 00-CT ESD safe carbon fiber replaceable tip tweezers-blunt tips.jpg EM-Tec 00.CT ESD safe carbon fiber replaceable tip tweezers, blunt tips
EM-Tec 00.CT ESD safe carbon fiber replaceable tip tweezers, blunt tips
Product # Unit Price* Add to Quote / Order
50-007000 each €21,00
Qty:



50-007020-EM-Tec 2A-CT ESD safe carbon fiber replaceable tip tweezers-flat wide tips.jpg EM-Tec 2A.CT ESD safe carbon fiber replaceable tip tweezers, flat wide tips
EM-Tec 2A.CT ESD safe carbon fiber replaceable tip tweezers, flat wide tips
Product # Unit Price* Add to Quote / Order
50-007020 each €21,00
Qty:



50-007025.jpg EM-Tec 2AB.CT ESD safe carbon fiber replaceable tip tweezers, flat wide curved tips
EM-Tec 2AB.CT ESD safe carbon fiber replaceable tip tweezers, flat wide curved tips
Product # Unit Price* Add to Quote / Order
50-007025 each €21,00
Qty:



50-007026.jpg EM-Tec 242.CT ESD safe carbon fiber replaceable tip tweezers, flat narrow tips
EM-Tec 242.CT ESD safe carbon fiber replaceable tip tweezers, flat narrow tips
Product # Unit Price* Add to Quote / Order
50-007026 each €21,00
Qty:



50-007027.jpg EM-Tec 249.CT ESD safe carbon fiber replaceable tip tweezers, blunt strong tips
EM-Tec 249.CT ESD safe carbon fiber replaceable tip tweezers, blunt strong tips
Product # Unit Price* Add to Quote / Order
50-007027 each €21,00
Qty:



50-007029.jpg EM-Tec 259.CT ESD safe carbon fiber replaceable tip tweezers, sharp tips
EM-Tec 259.CT ESD safe carbon fiber replaceable tip tweezers, sharp tips
Product # Unit Price* Add to Quote / Order
50-007029 each €21,00
Qty:



50-007050.jpg EM-Tec 5.CT ESD safe carbon fiber replaceable tip tweezers, sharp fine tips
EM-Tec 5.CT ESD safe carbon fiber replaceable tip tweezers, sharp fine tips
Product # Unit Price* Add to Quote / Order
50-007050 each €21,00
Qty:



50-007060.jpg EM-Tec 246.CT ESD safe carbon fiber replaceable tip tweezers, pointed, bent tips
EM-Tec 246.CT ESD safe carbon fiber replaceable tip tweezers, pointed, bent tips
Product # Unit Price* Add to Quote / Order
50-007060 each €21,00
Qty:



50-007070.jpg EM-Tec 7.CT ESD safe carbon fiber replaceable tip tweezers, fine curved tips
EM-Tec 7.CT ESD safe carbon fiber replaceable tip tweezers, fine curved tips
Product # Unit Price* Add to Quote / Order
50-007070 each €21,00
Qty:



50-007082.jpg EM-Tec 2AX.CT ESD safe carbon fiber replaceable tip reversed tweezers, flat wide tips
EM-Tec 2AX.CT ESD safe carbon fiber replaceable tip reversed tweezers, flat wide tips
Product # Unit Price* Add to Quote / Order
50-007082 each €23,25
Qty:



50-007085.jpg EM-Tec 5X.CT ESD safe carbon fiber replaceable tip reversed tweezers, sharp fine tips
EM-Tec 5X.CT ESD safe carbon fiber replaceable tip reversed tweezers, sharp fine tips
Product # Unit Price* Add to Quote / Order
50-007085 each €23,25
Qty:



50-001999.jpg EM-Tec locking ring for EM-Tec high precision tweezers, made from high strength Viton 90
EM-Tec locking ring for EM-Tec high precision tweezers, made from high strength Viton 90
Product # Unit Price* Add to Quote / Order
50-001999 pkg/10 €4,00
Qty:



Ordering information for the EM-Tec CT ESD safe replaceable tips

*Prices without VAT, but within the EU, we have to check for valid VAT-ID.

50-007R00.jpg EM-Tec 00.CTR ESD safe carbon fiber replaceable tips for EM-Tec 00.CT
EM-Tec 00.CTR ESD safe carbon fiber replaceable tips for EM-Tec 00.CT
Product # Unit Price* Add to Quote / Order
50-007R00 set of 2 €7,20
Qty:



50-007R20.jpg EM-Tec 2A.CTR ESD safe carbon fiber replaceable tips for EM-Tec 2A.CT
EM-Tec 2A.CTR ESD safe carbon fiber replaceable tips for EM-Tec 2A.CT
Product # Unit Price* Add to Quote / Order
50-007R20 set of 2 €7,20
Qty:



50-007R25.jpg EM-Tec 2AB.CTR ESD safe carbon fiber replaceable tips for EM-Tec 2AB.CT
EM-Tec 2AB.CTR ESD safe carbon fiber replaceable tips for EM-Tec 2AB.CT
Product # Unit Price* Add to Quote / Order
50-007R25 set of 2 €7,20
Qty:



50-007R26.jpg EM-Tec 242.CTR ESD safe carbon fiber replaceable tips for EM-Tec 242.CT
EM-Tec 242.CTR ESD safe carbon fiber replaceable tips for EM-Tec 242.CT
Product # Unit Price* Add to Quote / Order
50-007R26 set of 2 €7,20
Qty:



50-007R27.jpg EM-Tec 249.CTR ESD safe carbon fiber replaceable tips for EM-Tec 249.CT
EM-Tec 249.CTR ESD safe carbon fiber replaceable tips for EM-Tec 249.CT
Product # Unit Price* Add to Quote / Order
50-007R27 set of 2 €7,20
Qty:



50-007R29.jpg EM-Tec 259.CTR ESD safe carbon fiber replaceable tips for EM-Tec 259.CT
EM-Tec 259.CTR ESD safe carbon fiber replaceable tips for EM-Tec 259.CT
Product # Unit Price* Add to Quote / Order
50-007R29 set of 2 €7,20
Qty:



50-007R50.jpg EM-Tec 5.CTR ESD safe carbon fiber replaceable tips for EM-Tec 5.CT
EM-Tec 5.CTR ESD safe carbon fiber replaceable tips for EM-Tec 5.CT
Product # Unit Price* Add to Quote / Order
50-007R50 set of 2 €7,20
Qty:



50-007R60.jpg EM-Tec 246.CTR ESD safe carbon fiber replaceable tips for EM-Tec 246.CT
EM-Tec 246.CTR ESD safe carbon fiber replaceable tips for EM-Tec 246.CT
Product # Unit Price* Add to Quote / Order
50-007R60 set of 2 €7,20
Qty:



50-007R70.jpg EM-Tec 7.CTR ESD safe carbon fiber replaceable tips for EM-Tec 7.CT
EM-Tec 7.CTR ESD safe carbon fiber replaceable tips for EM-Tec 7.CT
Product # Unit Price* Add to Quote / Order
50-007R70 set of 2 €7,20
Qty:



50-007R82.jpg EM-Tec 2A.CTR ESD safe carbon fiber replaceable tips for EM-Tec 2AX.CT
EM-Tec 2A.CTR ESD safe carbon fiber replaceable tips for EM-Tec 2AX.CT
Product # Unit Price* Add to Quote / Order
50-007R82 set of 2 €7,20
Qty:



50-007R85.jpg EM-Tec 5.CTR ESD safe carbon fiber replaceable tips for EM-Tec 5X.CT
EM-Tec 5.CTR ESD safe carbon fiber replaceable tips for EM-Tec 5X.CT
Product # Unit Price* Add to Quote / Order
50-007R85 set of 2 €7,20
Qty:



50-007R87.jpg EM-Tec 7.CTR ESD safe carbon fiber replaceable tips for EM-Tec 7X.CT
EM-Tec 7.CTR ESD safe carbon fiber replaceable tips for EM-Tec 7X.CT
Product # Unit Price* Add to Quote / Order
50-007R87 set of 2 €7,20
Qty:



50-001999.jpg EM-Tec locking ring for EM-Tec high precision tweezers, made from high strength Viton 90
EM-Tec locking ring for EM-Tec high precision tweezers, made from high strength Viton 90
Product # Unit Price* Add to Quote / Order
50-001999 pkg/10 €4,00
